Product Details:
Payment & Shipping Terms:
|
Aplication: | Textile | Warranty: | 12 Months |
---|---|---|---|
Usage Strength: | Testing Machine | Others: | Can Be Customized |
Standards: | GB/T4744 FZ/T01004 AATCC 127 DIN 53886 JIS L1092 | Operation: | Manual+Automatic |
Power: | Ac 220V±10% 50HZ 200W | Weight: | 60kg |
High Light: | Textile Testing Machine,Fabric Inspection Machine |
100cm2 60KG Automatic Digital Fabric Water Permeability Tester with 12 Months Warranty
Applicable Range:
Used for testing the water permeability of compact fabrics, including canvas, coated fabrics, cover cloth, rainproof clothing fabrics and geotextile materials, ect.
Standards:
GB/T4744 FZ/T01004 AATCC 127 DIN 53886 JIS L1092
Testing mode:
1. Turbocharged;
2. constant pressure time;
3. constant pressure regularly;
4. flexing resistance relaxation method;
5. leakage water method
Specifications:
model | Testing range | Water tank lifting speed | Area of specimen gripholder |
-5 | 500pa-50kpa | 1kpa-20kpa | 100cm2 |
-20 | 500pa-200kpa | 1kpa-30kpa | |
-50 | 5kpa-500kpa | 1kpa-100kpa | 8cm2 |
-100 | custom-made |
Characteristics:
1. Computer program-controlled, LCD Chinese menu, built-in five sets of measurement mode
2. Built-in water tank design, original water rate balance system, with stable and accurate lifting speed
3. Pneumatic clamp
Technical parameters:
1. Power source: Ac 220V±10% 50HZ 200W
2. External dimension:560×400×600mm
3. Weight:60kg
Our service
1. High quality is always our key to market.
2. We will take photos or videos of your order before shipment.
3. Engineering team is professional and will provide you with good after-sales service.
The advantage of our company
1. Professional R&D team and cooperative factory can offer our clients OEM&customizing service.
2. Delivery time is fast and quick respond
3. Many years of experience in foreign export.
Our service
1. High quality is always our key to market.
2. We will take photos or videos of your order before shipment.
3. Engineering team is professional and will provide you with good after-sales service.
RFQ:
Why choose us?
1. Considerate Service Different countries plugs, manually change the-voltage from 110V to 220V, insurance indicator.
2. Excellent after sale service:
1 YEAR warranty. If you have any problems during testing process, we promise we will give you a reply with 24 hours and solution provide within 3 working days. What you need to do is to send us the controller.
3. Good Packaging:
Covered with air bubble film before put the machine into the wooden case, which not only has good shock absorption, impact resistance, heat sealing and also has the advantages of nontoxic, odorless, moisture corrosion, good transparency etc.
Pictures:
