| The Length Of The Piston Rod Head: | 6.350+/-0.100mm | Loaded Barrel Length: | 152+/-0.1mm |
|---|---|---|---|
| Temperature Resolution: | 0.1℃ | Timing Range: | 0.1-999 S |
| Measurement: | Quality Act (MFR) | The Diameter Of The Piston Rod Head: | 9.475+/-0.015mm |
| Usage: | Melt Flow Index MFI Tester | Dimensions: | 250*350*510(L*W*H) |
| Temperature Accuracy: | +/-0.2℃ | Timing Accuracy: | 0.1s |
| Highlight: | rubber testing equipment,universal test equipment |
||
250*350*510(L*W*H) Size Melt Flow Index Measurement , Electronic Plastic Testing Instrument
Discription:
KJ-3092 melt flow rate testing instrument can be used for ABS, polystyrene, polyethylene, polypropylene, polyamide, fiber resin, acrylate, POM, fluorine plastic, polycarbonate and other plastic materials, the melt flow rate (MFR) or the melt volume flow rate (MVR) to be determined.
Standard:
GB/T3682-2000,ISO1133-97, ASTM1238
Technical parameter:
| Model | KJ-3092 |
| Barrel parameters | Inner hole 9.55±0.025mm |
| Pistons parameters | Piston head: 9.475±0.015mm |
| Piston length | H=6.35±0.1mm |
| Paramters | Extrusion hole 1=2.095±0.005mm |
| Temperature parameter | With intelligent temperature control instrument, with four pairs of significant temperature setting control, PID parameters can be automatically set, precision up to ± 0.1 degree centigrade |
| Temperature range | 80degree centigrade~400degree centigrade |
| Temperature accuracy | ±0.2 degree centigrade |
| Display resolution | 0.1degree centigrade |
| Maximum comsuption | < 600W |
| Temperature recovery time | less 4 min. |
| Weight parameters are as follows: | |
| Weight accuracy | ±0.5% |
| Basic configuration | A 0.325kg (including binder bar) |
| B 1.2㎏, | |
| C 2.16㎏ | |
| D 3.8㎏ | |
| E 5.0㎏ | |
| F 10kg | |
| G 12.5㎏ | |
| H 21.6kg | |
| Position detection | |
| Loop distance from up and down | 30mm |
| Control precision | ± 0.1mm |
| Test flow control | |
| Times of cutting the material | 0~10 times |
| Material cutting interval | 0~999s(set reference Table 2) |
| Control flow reaches the set temperature without volatility | |
| Barrel temperature time | 15 min. |
| Material be installed | 1 min. |
| Material sample temperature recovery time | 4 min. |
| When binder set | 1min |
