Customized Adhesive Brake Shear Strength Tester Servo Motor Computer Control

Certification
China GUANGDONG KEJIAN INSTRUMENT CO.,LTD certification
China GUANGDONG KEJIAN INSTRUMENT CO.,LTD certification
Kejian Universal Testing Machine quality is the best,after-sale service is also great.

—— Oscar Vargas

Paper Testing Machine is one of the best product.

—— Kritsana Praikongkadhrama

I'm Online Chat Now

Customized Adhesive Brake Shear Strength Tester Servo Motor Computer Control

Customized Adhesive Brake Shear Strength Tester Servo Motor Computer Control
Customized Adhesive Brake Shear Strength Tester Servo Motor Computer Control Customized Adhesive Brake Shear Strength Tester Servo Motor Computer Control Customized Adhesive Brake Shear Strength Tester Servo Motor Computer Control

Large Image :  Customized Adhesive Brake Shear Strength Tester Servo Motor Computer Control

Product Details:
Place of Origin: China
Brand Name: KINSGEO
Certification: CE/ISO
Model Number: KJ-1066B
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: 4800 USD
Delivery Time: 15 work days
Payment Terms: T/T
Supply Ability: 30Sets/month
Detailed Product Description
Power: Electronic,220V/50HZ Usage: Universal Testing Machine,Paper Testing Instrument
Warranty: 1 Year Application: Adhesive Tape Tester
Standard: GB/T Measuring Range: 10~1000KN
Capacity: 200 Power Supply: AC220V 10% 50HZ
Dimention: 1050*750*2100mm Function: Adhesive Tape Test Machine
Accuracy: ±0.5% Accuracy Class: 0.5 Class
Max Load: 1000N Speed Of Test: 0.01-500mm/min
High Light:

Adhesive Brake Shear Strength Tester

,

Computer Control Peel Adhesion Tester

,

1050*750*2100 mm Peel Adhesion Tester

Usage

This machine also known as a materials testing machine , is applicable to testing tensile stress, compressive stress, shearing, force, peeling force, and elongation of materials, components, and finished product for metal, plastic, rubber, textile, synthetic, chemicals, wire and cable, leather, ect.

Character:

1. The structure is made of the paint-coated aluminium blanking plate. The interior is used the high-accuracy,low-resistance and zero clearance of two ball screw and oriented pole which improve loading efficience and structure rigidity.

2. Use Panasonic seveo motor which ensure high efficiency,steady transmission and low noise. The accuracy of speed can be controled in 2%.

3. That Using the business computer as the main control mathine plus the special testing software of our campany can conduct all of testing parameter, work state, collecting data&analysis, result display and printing output.
Specification
Capacity
5,10,20,50,100,200,500,1000,2000,5000KG
Stroke
800mm(not including fixture)
Test Speed
A: 0.5~1000mm/min; B: 50~500mm/min
(control by keyboard inputing)
Test range
400mm MAX
Dimention
80×50×150cm
Weight:
180kg
Accuracy
±0.5% or better
Operation method
computer control
Resolution
A: 1/250,000 B: 1/150,000
Motor
A: servo motor B: AC motor
Operation system
TM2101
Accessories:
customized clamps by appointed, force sensors, , printer, and operation manual
Power
1Ø,220V/50HZ
Stroke protection
Machinery, computer double protection, prevent over preset
Force protection
system setting
Emergency stop device
Handling emergencies
Standard:
GB16491-2008,HGT3844-2008 QBT11130-1991,GB 13022-1991,HGT 3849-2008,GB 6349-1986 GB/T 1040.2-2006
