100T Plastic Rubber Peel Adhesion Test Equipment With 0.5 To 1000mm / Min

China 100T Plastic Rubber Peel Adhesion Test Equipment With 0.5 To 1000mm / Min supplier
100T Plastic Rubber Peel Adhesion Test Equipment With 0.5 To 1000mm / Min supplier 100T Plastic Rubber Peel Adhesion Test Equipment With 0.5 To 1000mm / Min supplier

Large Image :  100T Plastic Rubber Peel Adhesion Test Equipment With 0.5 To 1000mm / Min

Product Details:

Place of Origin: China
Brand Name: KEJIAN
Certification: ISO, CE and ect.
Model Number: KJ-1066B

Payment & Shipping Terms:

Minimum Order Quantity: 1 set
Price: Negotiate
Packaging Details: Each set protected with resin fiber and PP film, then put into professional export Strong plywood case
Delivery Time: In stock, 3-7 working days after order confirmed
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram, In cash, escrow
Supply Ability: 200 sets per month
Contact Now
Detailed Product Description
Model: KJ-1065C Capacity: 10-200KG
Accuracy: ±0.5% Resolution: 1/500000
Unit: G,kg,N,KN,LB(switchover Free) Operation Method: Windows Operation
Sensor: USA Sensor Kind Of Drive: High-precision Ball Screw

100T Plastic Rubber Peel Adhesion Test Equipment With 0.5 To 1000mm / Min





Uses:



This machine also known as a materials testing machine , is applicable to testing tensile, compression,bending,peel, shearing force, peeling force, modulus of elasticity,and elongation of materials, components, and finished product for metal, plastic, rubber, textile, synthetic chemicals, wire and cable,leather,package,tape,

film,solar cell,ect.



Character:

1. The structure is made of the paint-coated aluminium blanking plate. The interior is used the high-accuracy,low-resistance and zero clearance of two ball screw and oriented pole which improve loading efficience and structure rigidity.

2. Use Panasonic seveo motor which ensure high efficiency,steady transmission and low noise. The accuracy of speed can be controled in 0.5%.

3. That using the business computer as the main control mathine plus the special testing software of our campany can conduct all of testing parameter, work state, collecting data&analysis, result display and printing output.



Accessories:

1. Suitable Grips that meet customer sample need.

2. Software for test control,data acquisition and report.

3. English operation teach video.

4. Tabel,computer is selectable.

5. Extensometer as customer need.



BESTE Software functions:

1. Use windows working platform, set all parameter with dialog forms and operate easy;

2. Using a single screen operation, do not need to change the screen;

3. Have simplified Chinese, traditional Chinese and English three languages,switch conveniently;

4. Plan test sheet mode freely;

5. Test data can be directly appeared in the screen;

6. Compare multiple curve data through translation or contrast ways;

7.With many units of measurement, the metric system and british system can switch;

8.Have automatic calibration function;

9.Have user-defined test method function

10.Have test data arithmetic analysis function

11. Have the function of automatic magnification, to achieve the most appropriate size of graphics;



Specification:



Design Standards GB16491-2008,HGT 3844-2008 QBT 11130-1991,GB 13022-1991,HGT 3849-2008,GB 6349-1986 GB/T 1040.2-2006 2411,ISO 4587,ISO/TS 11405,ASTM E4,BS 1610,DIN 51221,ISO 7500,EN 10002,ASTM D628,ASTM D638,ASTM D412.
Model KJ-1066A KJ-1066B
Range of speed 0.5-1000mm/min 50-500mm/min
Motor Japan Panasonic Servo Motor AC Motor
Capacity choice 5,10,20,50,100,200,500,1000,2000,5000KG optional
Resolution 1/250,000 1/150,000
Effective testing space 400mm MAX
Accuracy ±0.5%
Operation method Windows XP,Win7 operation,computer control
Accessories computer, printer, system operation manual
Optional accessories customized clamps by appointed, force sensors, , printer, and operation manual
Weight 400KG
Dimention (W×D×H)80×50×15cm
Power 1PH, AC220V, 50/60Hz
Stroke protection Upper and lower protection, prevent over preset
Force protection system setting
Emergency stop device Handling emergencies
