640mm×580mm×1300mm Size No Rotor Rheometer Plastic Testing Machine With Computer Control

Good quality Peel Adhesion Test Equipment for sales
Good quality Peel Adhesion Test Equipment for sales
Kejian Universal Testing Machine quality is the best,after-sale service is also great.

—— Oscar Vargas

Paper Testing Machine is one of the best product.

—— Kritsana Praikongkadhrama

I'm Online Chat Now

640mm×580mm×1300mm Size No Rotor Rheometer Plastic Testing Machine With Computer Control

China 640mm×580mm×1300mm Size No Rotor Rheometer Plastic Testing Machine With Computer Control supplier
640mm×580mm×1300mm Size No Rotor Rheometer Plastic Testing Machine With Computer Control supplier 640mm×580mm×1300mm Size No Rotor Rheometer Plastic Testing Machine With Computer Control supplier

Large Image :  640mm×580mm×1300mm Size No Rotor Rheometer Plastic Testing Machine With Computer Control

Product Details:

Place of Origin: Dongguan China
Brand Name: Kejian Kinsgeo
Certification: ISO,CE and etc
Model Number: KJ-A015

Payment & Shipping Terms:

Minimum Order Quantity: 1 set
Price: Negotiate
Packaging Details: Each set protected with resin fiber and PP film, then put into Professional Plywood Strong wooden case
Delivery Time: 5-10 working days after order confirmed
Payment Terms: L/C,D/A,D/P,T/T,Western Union,MoneyGram,In cash, escrow
Supply Ability: 100 Sets per Month
Contact Now
Detailed Product Description
Usage Strength: Testing Machine Aplication: Plastic
Warranty: 12 Months Outside Size: 640mm×580mm×1300mm
Power: 220V±10% 50HZ Weight: 210kg
Torque Range: 0N.m—5N.m Rotor Pendulum Angle: ±0.5 (amplitude Is 1)

640mm×580mm×1300mm Size No Rotor Rheometer Plastic Testing Machine With Computer Control





Specification:



Temperature range room temperature—200℃
Temperature fluctuation range ±0.1℃
Temperature resolution 0.1℃
Heating speed room temperature—200℃,about 10 min
Torque range 0N.m—5N.m
Testing time setting

3min--120min,choose freely

Rotor pendulum angle ±0.5 (amplitude is 1)
Die body pendulum frequency 1.7Hz±0.1Hz(100r/min)
Consumed power 800W
Power 220V±10% 50HZ
outside size 640mm×580mm×1300mm
weight 210kg
Print content Data,time,temperature, vulcanization curve,temperature curve




Use:



This machine is designed by GB/T16584





Software Introduction:



A. Testing standardization:GB/T16584ISO6502:1991 and ASTMD5289-95.

B. Specimen information:set the material no,like “RBS6".User can set the title freely.

C. High quality function:You can modify the testing time when in operation.For example:When you set 20min to finish vulcanization,when in testing to 11min,you find the rubber material can finish vulcanization in 9min,and no need to test longer.You can modify the test time in software to 9min,the test will stop in 9min,and will draw integrity vulcanization curve and calculate the test data.If you test 18min,19min will finish,but it doesn't finish vulcanization,need to continue testing,or the testing data will be wrong.At this time,you can set the test time longer,modify 25min or more,Until the vulcanization finishing.It can time and rubber material.

D. Graph curve scale automatic optimization(Auto Scale),after testing,software can according to test data size to adjust Y scale,according to 0—5 Mv 0—10Mv 0-20Mv,making testing curve more beautiful,for different material,you can also compare the data in software.





RFQ:

Why choose us?

1. Considerate Service Different countries plugs, manually change the-voltage from 110V to 220V, insurance indicator.

2. Excellent after sale service:
1 YEAR warranty. If you have any problems during testing process, we promise we will give you a reply with 24 hours and solution provide within 3 working days. What you need to do is to send us the controller.

3. Good Packaging:
Covered with air bubble film before put the machine into the wooden case, which not only has good shock absorption, impact resistance, heat sealing and also has the advantages of nontoxic, odorless, moisture corrosion, good transparency etc.


Pictures:


640mm×580mm×1300mm Size No Rotor Rheometer Plastic Testing Machine With Computer Control
