400W 500kg ASTM D903 Universal Testing Machines Servo Control

400W 500kg ASTM D903 Universal Testing Machines Servo Control
400W 500kg ASTM D903 Universal Testing Machines Servo Control 400W 500kg ASTM D903 Universal Testing Machines Servo Control 400W 500kg ASTM D903 Universal Testing Machines Servo Control

Large Image :  400W 500kg ASTM D903 Universal Testing Machines Servo Control

Product Details:
Place of Origin: Dongguan,China
Brand Name: KEJIAN
Certification: ISO,CE and etc.
Model Number: KJ-1069
Payment & Shipping Terms:
Minimum Order Quantity: 1 Unit
Price: Negotiate
Packaging Details: Each set protected with resin fiber and PP film, then put into professional export Strong plywood case
Delivery Time: In stock,3-7 working days after order confirmed
Payment Terms: L/C,D/A,D/P,T/T,Western Union,MoneyGram,In cash, escrow
Supply Ability: 200 sets per month
Detailed Product Description
Name: High-Speed Peel Strength Tester Motor:: Panasonic Servo Motor
Test Speed:: 50~5,000mm/min Control: PC
Accuracy: 0.5 Class Capacity: 1,2,5,10,20,50,100,200,500kg Optional
Aplication: Rubber ,plastic ,nylon ,leather And Etc Design Criteria: ASTM D903,GB/T16491 And Etc
Maximum Trip:: 1000mm Driving Method: High Precise Ball Screw
Grips: Different Material And Test Method With Different Grips Warranty: 12 Months
High Light:

400W Universal Testing Machines

,

ASTM D903 Universal Testing Machines

,

1000mm Peel Strength Tester


400W 500kg ASTM D903 Universal Testing Machines Servo Control

Usage
This machine is equipped with different fixtures to test 90°peel strength, 180°peel strength and release strength of tape and adhesive brand products. It can show the adhesion performance of tape products. And it can also test the tensile strength of base material. In addition, the instrument can do pressure and tensile testing through software.
Standard

ASTM D3330, FINAT, GB/T2792, PSTC and etc.

Feature

It can be used to test the material with 0.5g/25mm minimum testing accuracy, which improves the quality level of products in the electronic materials industry.

Technical Parameter

Capacity2kg
Accuracy class0.5 class
Maximum load2kg/5kg
Effective range of force measurement0.02/100~100%
Effective testing width100mm
Effective tensile space1,000mm
Testing speed50~5,000mm/min
Speed accuracy±0.5%
Accuracy of displacement measurement±0.5%
SensorAmerican high -precision sensor
Control systemServo motor and driver
Resolution of testing forceMaximum load: 250,000yards
Software measurement&control systemFull digital closed-loop system
Lifting gear of testing benchComputer digital control/manual touch control
Safety protection device of testing benchSoftware automatic diagnosis and electronic limit
Testing regressionThe manual regression can return to the initial position at the fastest speed. The automatic regression can return automatically after finishing the test.
Overload protectionIt can set the maximum load value to protect itself automatically.
Frock clamp equipmentCustomized
Power400W
WeightAbout 55kg



Pictures:

400W 500kg ASTM D903 Universal Testing Machines Servo Control 0
400W 500kg ASTM D903 Universal Testing Machines Servo Control 1



FAQ

1. Q: What is your warranty ?
- 12 months product warranty, but lifetime for services.Free Non-consumable components will be provided if any performance failure occurs within 12 months caused by non-human damage.

Tensile Testing Machine

2. Q: How-to vedio provided ?
- Yes, if required, our engineers will record a specialize how-to video for you.

Tensile Testing Machine

3. Q: 1.Are your company a trading one or a factory?
- Yes, we are a manufactured factory+ trade (integration),18 years focusing on test instruments field,9 years exporting experience.,warmly welcome to visit our plant(factory), we also support OEM and ODM.

Tensile Testing Machine

4. Q: After an order is placed, when to deliver?
- Generally about 25 days, If we have inventory, we can arrange shipment within 3 days.
Please be aware that our production lead times depend on specific items and item quantities.

5. Q: What about the warranty with after - sales services?
- 12 months warranty. Besides,we can help you to repair your problem controller freely,even it's not from our factory.
What you need to do is to send us the controller.
After the warranty, the professional after-sale service team will provide perfect technical support,and help customer solve problems encountered
while using our product, handles guest problems and complaints in a professional and timely.

Tensile Testing Machine

6. Q: What about the services and product' quality?
- Each instruments must be carried out 100% quality examination and test when shipping and delivery goods.
Product use training, each of our product provide video training to show you how to install & operate.
Engineers would be go abroad to training, repair and others help you need.



400W 500kg ASTM D903 Universal Testing Machines Servo Control 2
