240kg Economic CNC Optical Coordinate Measuring Machine 50HZ 30W VMS-4030

China 240kg Economic CNC Optical Coordinate Measuring Machine 50HZ  30W VMS-4030 supplier
240kg Economic CNC Optical Coordinate Measuring Machine 50HZ  30W VMS-4030 supplier 240kg Economic CNC Optical Coordinate Measuring Machine 50HZ  30W VMS-4030 supplier 240kg Economic CNC Optical Coordinate Measuring Machine 50HZ  30W VMS-4030 supplier

Large Image :  240kg Economic CNC Optical Coordinate Measuring Machine 50HZ 30W VMS-4030

Product Details:

Place of Origin: Dongguan China
Brand Name: Kejian
Certification: ISO, CE and SGS
Model Number: KJ-4030

Payment & Shipping Terms:

Minimum Order Quantity: 1 set
Price: Negotiate
Packaging Details: Each set protected with resin fiber and PP film, then put into Professional Plywood Strong wooden case
Delivery Time: Standard size in stock,3-7 working days after order confirmed
Payment Terms: L/C,D/A,D/P,T/T,Western Union,MoneyGram,In cash, escrow
Supply Ability: 100 Sets per Month
Contact Now
Detailed Product Description
Certification: CE,ISO,SGS Keyword: Coordinate Measuring Machine
APLICATION: Optical Instruments DIGITAL RESOLUTION: 0.001mm
WEIGHT: 240kg WORKING DISTANCE: 108mm
Z-AXIS LIFT: 150 Mm POWER: 220V (AC), 50HZ, 30W

240kg Economic CNC Optical Coordinate Measuring Machine 50HZ 30W VMS-4030





Product Discription:



VMS-4030 Economic Cnc Optical Coordinate Measuring Machine applies to the second coordinate measurement for the purpose of all applications, machinery, electronics, instrumentation, plastics and other industries widely used.





Product Feature:



  • 1Apparatus with RS-232 interface ,when connected to the computer, special measurement software M2D can process and output the mapping graph.
  • Apparatus using color CCD camera, zoom lens and the cross line generator as a measure aiming system;
  • Grating electric box with the composition of DC-3000 Digital Measurement and data processing systems;
  • Apparatus with a variety of data processing, display, input, output, particularly useful piece straighten function; users matching the printer according to their needs and target different measurement systems.

240kg Economic CNC Optical Coordinate Measuring Machine 50HZ  30W VMS-4030



Product Function:



Element Measurements Multi-point measurement point, line, circle, arc, angle, ellipse, rectangle measuring points provided, automatic identification of point, line, circle, arc.
Element Structure The center structure, the intersection of structure, the mid-point structure, line structure, a round structure, the angle structures
Preset Elements Point, line, circle, arc.
Graphics Coordinate translation, straighten the workpiece.
Arbitrary axis straightened, coordinate system reset.
Graphic to enlarge, reduce graphics, graphics translation, graphic printing graphic is selected, uncheck, graphics removed.
Set the zoom, graphics narrow, graphic print radio is selected, deselect, graphics removed
Set the gray scale image, saturation, contrast, image saved as a BMP format.
A variety of edge detection mode, the computer automatically get points, automatic identification circle, arc greatly enhance the Speed of mining points.
Image support S video input;
Image size 640 * 480mm.





Software's common feature:



  • multi-point measurement point, line, circle, arc, ellipse, improving measurement accuracy.
  • straightened coordinates translation and coordinate measurement more convenient and efficient, improve the measurement efficiency.
  • convenient combination of elements, users simply click graph could be composed of point, line, circle, distance, angle.
  • macro commands, batch jobs with a kind of measurement is more convenient, made of high measurement efficiency.
  • measurement data directly to AutoCAD, the measurement of the graphics can be saved dxf document.
  • measurement data can be sent to Excel, for statistical analysis, can draw a simple Xbar-S control chart, calculated Ca, and other parameters.
  • multilingual interface switching.
  • record user program, editing commands, taught to perform.

240kg Economic CNC Optical Coordinate Measuring Machine 50HZ  30W VMS-4030

Parameter:



Model VMS-4030

Table



Metal table size (mm) 606 ×466
Glass table size (mm) 450 ×350
Travel mileage (mm) 400 ×300
Weight( kg ) 240

Measurement and aiming system



Camera: Color 1 / 3 "CCD camera Zoom lens magnification: 0.7 ~ 4.5 ×
Video Total magnification: 30 ~ 230 × Field of view objects: 7 ~ 1.1mm
Working distance: 108mm
Z-axis lift: 150 mm

Digital Resolution: 1μm



X.Y coordinate measuring indication error ≤ 3 + L/200) μm
Lighting: Surface light and transmission light are using LED, adjustable brightness Power: 220V (AC), 50HZ, 30W
Measurement software: standard with automatic measurement software can automatically find edges, deburring, measurable point, line, circle, center distance, angle, put right, etc.




FAQ:




Why choose us?

Good Packaging:
Covered with air bubble film before put the machine into the wooden case, which not only has good shock absorption, impact resistance, heat sealing and also has the advantages of nontoxic, odorless, moisture corrosion, good transparency etc.
